Liquid Samplers
BURKLE INC MiniSampler PTFE, complete
With the vacuum sampler MiniSampler, the sample liquid only comes into contact with the suction hose and the original sample bottle. The possibility of cross-contamination is greatly reduced. Immediately after taking the sample, the bottles are sealed. The disposable suction hose can quickly be replaced. This guarantees that the samples are never contaminated. If necessary, a new hose can be used for every single sample.
Due to its small diameter (8 mm (0.31 in.)), the hose can reach narrow, seemingly inaccessible sampling areas.
BURKLE INC Target immersion cylinder, 16.91 oz. (500 ml), Ø 2.95 in. (75 mm), hose 16.40 ft. (5 m)
Precise liquid samples can be taken with the Target immersion cylinder.
BURKLE INC LiquiSampler, PTFE/FEP, 5.07 oz. (150 ml) vol., 23.62 in. (60 cm), Ø 1.26 in. (32 mm)
LiquiSampler for liquids, according to DIN EN ISO 15528. Made of ultra pure and chemically inert PTFE/FEP or PP for contamination-free sampling.
Sampling from open and closed containers, barrels, tanks, silos, water courses. Suitable for all commercially available barrels and containers with opening of at least 1.26 in. (32 mm) (1.26 in.) in diameter.
Easy cleaning - all surfaces are free of pores and crevices, preventing accumulation of dirt. Only round screw threads proven in foodstuffs hygiene are used. Disassembly and cleaning are extremely simple.
BURKLE INC Telescopic rod, infinitely adj. 49.21–98.43 in. (125–250 cm), 2 rods
Different tools can be attached to the telescopic rod (snap-in joint). The individual rods have been provided with an end stop. This means that one rod cannot accidentally slip out of another rod.
The telescopic rods cannot be rotated radially, which means even better handling!
Telescopic rod 5355-0280, extremely short model – yet extendable up to 280 cm (110.24 in.). Fits into every car trunk!
BURKLE INC ViscoDispo LaboPlast, HDPE, 39.37 in. (1000 mm), 6.76 oz. (200 ml)
The ViscoDispo disposable sampler can be used to take samples of high-viscosity media up to 100,000 mPas. The cleanroom-manufactured and individually packaged design ensures safe and contamination-free sampling. The ergonomically shaped handle and the very stable drawbar make it easy to draw even viscous substances.
BURKLE INC Profi Sampler PP, complete
While the MiniSampler is designed for laboratory use, the ProfiSampler has been specially developed for rough industrial use.
Vacuum samplers have the advantage that the sample liquid only comes into contact with the suction hose and the original sample bottle. The possibility of cross-contamination is greatly reduced. Immediately after taking the sample, the bottles are sealed. The disposable suction hose can quickly be replaced. This guarantees that the samples are always authentic. If necessary, a new hose can be used for every single sample.
Due to its small diameter (8 mm (0.31 in.)), the hose can reach narrow, seemingly inaccessible sampling areas.
BURKLE INC ViscoSampler, PTFE/FEP, volume 5.41 oz. (160 ml), 23.62 in. (60 cm), Ø 1.26 in. (32 mm)
ViscoSampler with powerful suction for viscous media. The media is drawn up and discharged using the suction flask. Made of ultra-pure, chemically inert PTFE/FEP for contamination-free sampling.
Easy cleaning - all surfaces are poreless and without crevices. Dirt accumulation is prevented. Only round screw threads tried and tested in the field of food hygiene are used. Disassembly and cleaning are extremely simple.
BURKLE INC LiquiSampler, PTFE/FEP, 16.91 oz. (500 ml) vol., 78.74 in. (200 cm), Ø 1.26 in. (32 mm)
LiquiSampler for liquids, according to DIN EN ISO 15528. Made of ultra pure and chemically inert PTFE/FEP or PP for contamination-free sampling.
Sampling from open and closed containers, barrels, tanks, silos, water courses. Suitable for all commercially available barrels and containers with opening of at least 1.26 in. (32 mm) (1.26 in.) in diameter.
Easy cleaning - all surfaces are free of pores and crevices, preventing accumulation of dirt. Only round screw threads proven in foodstuffs hygiene are used. Disassembly and cleaning are extremely simple.
BURKLE INC QualiSampler set PP, complete with carrying case
The handy QualiSampler set, complete with a carrying case, combines the LiquiSampler and ViscoSampler—both made from PP—along with practical accessories. It is perfectly suited for sampling liquids and viscous substances.
BURKLE INC ViscoSampler, PP, volume 22.01 oz. (650 ml), 78.74 in. (200 cm), Ø 1.26 in. (32 mm)
ViscoSampler with powerful suction for viscous media. The media is drawn up and discharged using the suction flask. Made of ultra-pure, chemically inert PTFE/FEP for contamination-free sampling.
Easy cleaning - all surfaces are poreless and without crevices. Dirt accumulation is prevented. Only round screw threads tried and tested in the field of food hygiene are used. Disassembly and cleaning are extremely simple.
BURKLE INC Manually-operated reel PA, electrically conductive
The manually-operated drum reels can be equipped with various cables or chains.
If flammable or highly flammable liquids are to be collected, then electrically conductive manually-operated drum reels must be used together with a grounding cable. The dipping bottles must be made of non-sparking metal.
BURKLE INC QualiSampler set PTFE/FEP, compl. with carrying case
The handy QualiSampler set, complete with a carrying case, combines the LiquiSampler and ViscoSampler—both made from PTFE/FEP—along with practical accessories. It is perfectly suited for sampling liquids and viscous substances.
