Reaction Kettles
Ace Glass, Inc. 1L Instatherm filter reactor body with 100mm ID grooved top flange, #80 bottom thread, 100mm IDx180mm depth, with CAPFE O-ring and power cord, 120v/5amp max
1L Instatherm coated filter reactor body with a 100mm I.D. grooved top flange for connection to a reaction head with the use of a quick release clamp, and a #80 Ace-Thred bottom thread for use with a bottom adapter with a filter support and drain valve. Instatherm provides safer, rapid heating, and can be operated at 115v with ACE Proportional Temperature Controllers, or with a Powerstat. Reactor body supplied with a CAPFE o-ring and a power cord. Dimensions: 100mm I.D. x 180mm D.
Ace Glass, Inc. 1000mL pressure vessel body, one-piece, jacketed, #25 center neck, (3) #15 and (1) #7 side necks, 0-8mm 28/15 ball joint bottom outlet, #11 Ace-Thred connection on jacket inlet/outlet for use with 3/8in ID tubing.
1000mL pressure vessel body, one-piece, jacketed, #25 center neck, (3) #15 and (1) #7 side necks, 0-8mm 28/15 ball joint bottom outlet, #11 Ace-Thred connection on jacket inlet/outlet for use with 3/8in ID tubing.
Ace Glass, Inc. 2000mL, one-piece jacketed pressure reactor with #25 center, (3)#15, (1)#7 side necks, 0-8mm valve and 28/15 ball joint bottom outlet, 28/15 ball joint inlet/outlet, complete with addition funnel, condenser, manifold & stirring assemblies
Complete, one-piece 2000mL jacketed pressure reactor is designed to perform low to moderate positive pressure reactions, synthesis, and catalysis. Flask has a #25 center neck, (3) #15 side necks, and (1) #7 side neck. Flask bottom outlet is 0-8mm 28/15 ball joint. Jacket inlet/outlet has a 28/15 o-ring ball joint. Rated 45 PSI at 100 degrees C. Reactor system includes addition funnel, condenser, manifold, and stirring assemblies.
Ace Glass, Inc. Head, 150mm Duran flange, O-ring groove, #15 center, (4)#15, (1)#7
Head, 150mm Duran flange, O-ring groove, #15 center, (4)#15, (1)#7
Ace Glass, Inc. 150mL Instatherm filter reactor body with 60mm ID grooved top flange, #50 bottom thread, 60mm IDx75mm depth, with CAPFE O-ring and power cord, 40v/6amp max
150mL Instatherm coated filter reactor body with a 60mm I.D. grooved top flange for connection to a reaction head with the use of a quick release clamp, and a #50 Ace-Thred bottom thread for use with a bottom adapter with a filter support and drain valve. Instatherm provides safer, rapid heating, and can be operated at 115v with ACE Proportional Temperature Controllers, or with a Powerstat. Reactor body supplied with a CAPFE o-ring and a power cord. Dimensions: 60mm I.D. x 75mm D.
Chemglass Life Sciences 7-Neck PTFE Reaction Vessel Lid, 100mm, 24/40 Outer, 92mm Overall Height
7-Neck PTFE Reaction Vessel Lid, 100mm, 24/40 Outer, 92mm Overall Height. Reaction vessel lid is constructed entirely of PTFE. Low-form lid has seven openings: (A) center neck 3/4 female NPT for PTFE standard taper adapter, (B) side necks 3/4 female NPT, vertical for PTFE standard taper adapters, (C) side neck 1 female NPT with 10 X 10 compound angle for PTFE compression fitting used with Lasentec Probe, and (D) side necks 1/4 female NPT. Lid is supplied complete with listed PTFE standard taper adapters for center and vertical side necks, 14mm PTFE compression fitting for 10 X 10 compound angle side neck, and three 1/4 male NPT PTFE plugs. For clamp see CG-141 or CG-141-T. For o-ring see CG-147. Special neck sizes and configurations are available. Please contact us for details. PLEASE NOTE: DUE TO SPACE CONSTRAINTS ON THE LID, WE RECOMMEND USING THE CG-2077 OR CG-2077-H 10MM PTFE BEARING WITH THE LOOSENING NUT REMOVED.
Chemglass Life Sciences 4000ml Reaction Vessel, Cylindrical, 150mm Schott O-Ring Flange, 160mm O.D. x 355mm Height
4000ml Reaction Vessel, Cylindrical, 150mm Schott O-Ring Flange, 160mm O.D. x 355mm Height. Cylindrical reaction vessel constructed with a flange having a groove formed in the sealing surface of the flange. Flange is also ground to permit a greased seal with any of the lids CG-1940 through CG-1946. For clamp see CG-141 or CG-141-T, for o-ring see CG-147.
Chemglass Life Sciences 2L Reaction Vessel, Jacketed, 150mm Schott O-Ring Flange, GL-18 Inlet/Outlet, CG-511-02 Drain Valve
2L Reaction Vessel, Jacketed, 150mm Schott O-Ring Flange, GL-18 Inlet/Outlet, CG-511-02 Drain Valve. Features: • Chemically Resistant Perfluoro O-Rings On Drain Valves• Graduation Scale On Both Sides Showing Approximate Volume• Sidearm on Lower Drain Valve Can Be Used With a Standard 1/2 or 3/4in TFE, PFA or PP Compression Fitting• All Vessels Are Serial Numbered• GL Thread Inlet/Outlets Are Supplied With Removable High Temperature PFA Hose Connections And PPS Screw Caps• 3/4in Beaded Pipe Inlet/Outlets Are For Use With CG-1968-70 Couplings, CG-1969-A-03 Or CG-1964-42 Adapters
Ace Glass, Inc. 1000mL pressure vessel body, one-piece, jacketed, #25 center, (3) #15, (1) #7 side necks, round bottom, #11 Ace-Thred connections on jacket inlet/outlet, use 3/8in tubing.
1000mL one-piece jacketed round bottom pressure vessel with a #25 center neck, (3) #15 and (1) #7 side necks, and a #11 Ace-Thred connection for 3/8 tubing on the jacket inlet/outlet. Vessel is part of pressure reactor system designed to perform low to moderate positive pressure reactions, synthesis and catalysis. Rated at 45psi at 100 degrees Centigrade.
Ace Glass, Inc. Head, solvent distillation, No-Air, 1000mL, 24/40 joints, 14/20top take-off
Head, solvent distillation, No-Air, 1000mL, 24/40 joints, 14/20top take-off
Ace Glass, Inc. Head, solvent distillation, No-Air, 500mL, 24/40 joints, 14/20top take-off
Head, solvent distillation, No-Air, 500mL, 24/40 joints, 14/20top take-off
