HPLC Columns and Cartridges
YMC America, Inc Cell-SB col 3um 75x2mm
YMC s CHIRAL ART series features polysaccharide-derived chiral stationary phases (CSPs) based on amylose and cellulose tris-carbamate derivatives available in both coated and immobilized formats These columns provide exceptional stereoselectivity durability and solvent versatility supporting normal-phase reversed-phase and supercritical fluid chromatography (SFC) modes
YMC America, Inc SIL 60A 5um 150x0.3mm 1/16
The high-purity silica found in YMC-Pack SIL columns provides virtually complete sample recovery The absence of silica impurities reduces non-specific sample adsorption and the totally porous nature of the silica provides high sample loading The elevated chemical purity of YMC silica results in a particle structure exhibiting high mechanical strength YMC-Pack SIL is suitable for separation of fat-soluble compounds using non-polar mobile phases as well as the separation of positional isomers that are difficult to separate in reversed-phase mode SIL-06 (60 pore size) has greater adsorption properties than SIL (120 pore size) due to its larger surface area and is generally useful for separating natural products with low molecular weight
YMC America, Inc NH2 120A 5um 75x0.5mm 1/32
YMC-Pack NH2 is a normal phase separation column utilizing the polarity of primary amino groups bonded to silica It is a versatile stationary phase often used for the separation of sugars but can also be used for separations utilizing weak anion-exchange
YMC America, Inc SIL 120A 5um 100x0.1mm 1/16
The high-purity silica found in YMC-Pack SIL columns provides virtually complete sample recovery The absence of silica impurities reduces non-specific sample adsorption and the totally porous nature of the silica provides high sample loading The elevated chemical purity of YMC silica results in a particle structure exhibiting high mechanical strength YMC-Pack SIL is suitable for separation of fat-soluble compounds using non-polar mobile phases as well as the separation of positional isomers that are difficult to separate in reversed-phase mode SIL-06 (60 pore size) has greater adsorption properties than SIL (120 pore size) due to its larger surface area and is generally useful for separating natural products with low molecular weight
YMC America, Inc ODS-A 200A 3um 5x0.3mm 1/32
YMC-Pack ODS-A is a high-coverage fully-endcapped C18 phase which exhibits exceptional lot-to-lot reproducibility It is available in three different pore sizes and is suitable for the separation of a wide range of compounds YMC-Pack ODS-A in 120 pore size is used for high performance reversed phase separations It has selectivity for the separation of many organic compounds found in pharmaceutical chemical and biotechnology industries 200 ODS-A offers a unique mix of moderately large pores and high surface area for the analysis of compounds ranging from small organics and pharmaceuticals to moderately-sized proteins
Waters Corp Spherisorb Amino (NH2) Column, 80Å, 5μm, 4.6 mm × 100 mm
Spherisorb NH2 (Amino) columns contain a silica-based aminopropyl bonded sorbent. The column is listed as USP L8 and is used for anion-exchange, normal-phase and HILIC separations.
- Amino (NH2) chemistry
- Normal-phase separation mode
- pH range: 2 pH to 8 pH
- Maximum pressure: 6000 psi (415 Bar)
- Not endcapped
- High silanol activity
- Spherical particle shape
- Particle size: 5 μm
- Parker-style endfitting
- Column format
- Surface area: 220
- HPLC system compatibility
- USP classification: L8
- Carbon load: 2 %
- Inner diameter: 4.6 mm
- Length: 100 mm
- Pore size: 80 Å
Waters Corp Waters XSelect Column, Phenyl-Hexyl, 5 μm, 4.6 mm x 75 mm
XSelect CSH Phenyl-Hexyl columns offer an alternative analyte selectivity compared to traditional reversed-phase columns, making them a valuable tool for method development. The trifunctionally bonded C6 phenyl-ligand provides a robust, low bleed sorbent that selectively retains polyaromatic compounds through pi-pi interactions.
- Particle size: 5 μm
- Column dimensions: 4.6 mm × 75 mm
- Bonding technology: Phenyl-Hexyl
- Separation mode: Reversed Phase
- Particle substrate: Hybrid
- pH range: 1 to 11
- Maximum pressure: 6000 psi (415 Bar)
- Endcapped: Yes
- Silanol activity: Low
- Particle shape: Spherical
- Pore size: 130 Å
- Surface area: 185
- System: HPLC
- USP classification: L11
- Carbon load: 14%
- Units per package: 1
Waters Corp Waters RP/HILIC UPLC Method Development Kit, 2.1 mm, 50 mm, 1.7 μm
This novel reversed-phase and HILIC UPLC method development approach integrates 1.7 μm BEH C18, Shield RP18, and Amide with 1.8 μm HSS C18 SB to facilitate efficient and effective method development. This innovative approach offers a comprehensive combination of selectivity choices, enabling the effortless retention and resolution of compounds across a broad polarity range.
- pH range of 1 to 12
- Maximum pressure of 18000 psi (1240 bar)
- Not endcapped
- Spherical particle shape
- Particle size of 1.7 μm
- Parker-style endfitting
- Pore size of 130 Å
- Method development kit format
- Compatible with UPLC and UHPLC systems
- Inner diameter of 2.1 mm
- Length of 50 mm
- Features eCord technology
- 4 units per package
Waters Corp WATERS CORPORATION XSelect CSH C18 Column, 1.0 x 150 mm, 3.5 μm, 130 Å
The XSelect CSH C18 column leverages Charged Surface Hybrid (CSH) Technology for superior selectivity and high analyte loading in UPLC®, HPLC, and preparative separations. This technology boosts LC column performance in acidic, low ionic strength mobile phases and improves chromatographic peak shape.
- Provides enhanced selectivity for acidic, alkaline, and neutral compounds.
- Offers seamless scalability across UPLC and HPLC platforms.
- Features CSH C18 chemistry with trifunctional C18 ligand, 15% carbon load, and proprietary endcap style.
- Pore diameter of 130 Å and surface area of 185 m²/g.
- Stable across a pH range of 1–11.
- Operating temperature limits: 80 °C at low pH, 45 °C at high pH.
- Available in scalable particle sizes including 2.5, 3.5, and 5 μm.
Waters Corp HPLC Column, XSelect HSS PFP, 4.6 x 50 mm, 3.5 μm
These XSelect HSS PFP columns are part of the XSelect HPLC Columns family, offering selective modern HPLC capabilities. They incorporate High Strength Silica (HSS) Technology, designed to complement the chromatographic performance of BEH and CSH particles.
- Ligand type: trifunctional pentafluoro-phenyl
- Ligand density: 3.2 μmol/m2
- Carbon load: 7%
- Endcap style: none
- USP classification: L43
- pH range: 2 to 8
- Low pH temperature limit: 45 °C
- High pH temperature limit: 45 °C
- Pore diameter: 100 Å
- Surface area: 230 m2/g
- Particle size: 3.5 μm
- Dimensions: 4.6 x 50 mm
- Offers useful alternatives to standard C18 phases for selectivity of bases or planar aromatic compounds
