Distillation Labware
Glassware and replacement parts designed to carry out distillations in laboratory settings; includes condensers, distillation heads, receivers, etc. Products are available for various scales and for specialty distillations.
Distillation is a process used widely in the laboratory or in wider working environments for separating or purifying liquids or liquid mixtures based on the different boiling points of individual components.
Distillation Applications:
• Separation and purification of miscible liquid mixtures in organic chemistry
• Drying of solid residues and/or solvent removal
• Fractional distillation of liquids from polymers and petroleum products
• Removal of particulates or other solid contaminants
• As part of a water purification system for production of distilled water for laboratory use
• Specialist steam distillation-based applications such as Kjeldahl analysis of nitrogen and proteins in food, beverage, or environmental samples
What Types of Distillation Equipment Are Available?
Conventional distillation apparatus, typically comprising individual, jointed borosilicate glassware components assembled by the user (depending upon the application), using appropriate clamps, stands, and supports. Most conventional distillation assemblies combine a round-bottomed distilling flask to contain and heat the liquid(s) that require purification, fitted with a stoppered or jointed neck to which is attached a downward-sloping, inclined side-arm for connection to a condensing unit to cool the heated vapors back down to their liquid state. Heating mantles are the preferred heat source for improved temperature control. These conventional distillation units are also available supplied complete and ready-assembled for added convenience and ease of use.
Specialized automated distillation equipment, notably units designed for the determination of volatile acidity and alcoholic strength by volume in wines, musts, and alcoholic beverages, and units designed for Kjeldahl nitrogen or protein determinations.
Ace Glass, Inc. Short path still, 500mL, complete with distillation flask, gas inlet tube with adapter, 24/40 still body, thermometer, cow receiver and (3)250mL receiving flasks
24/40 jointed short path still. Extension tube from still body allows positioning of drop directly over receiver flask. Gas inlet tube is positioned in the distillation flask with an ACE 5028 adapter and secured with a #7 Ace-Thred. Thermometer joint is 10/30. Complete system consists of 500mL distillation flask, still body, cow receiver, gas inlet tube, threaded adapter, 3 250mL receiver flasks and a thermometer.
Ace Glass, Inc. 24/40 50mL distillation receiver
50mL all-purpose receiver for general distillation work. Equipped with a complete stopcock manifold to allow contents of the receiver to be removed to a single receiving flask without disturbing the vacuum of the system
Ace Glass, Inc. Extractor body, 5000mL, 82in Soxhlet apparatus, 145/60 top55/50 bottom
EXTRACTOR BODY 5000ML
Ace Glass, Inc. 30cm Congealing temperature wire stirrer with #3 stopper
30cm congealing temperature wire stirrer with #3 stopper, part of the ACE congealing temperature distillation apparatus, which is similar to that described in U.S. Pharmacopeia, 1995, page 1780. The ACE apparatus is supplied with Ace-Threds in place of rubber stoppers, where practical.
Ace Glass, Inc. Vigreux column, 24/40, 18 inch effective length
Vigreux column, 24/40, 18 inch effective length
Ace Glass, Inc. Receiver, distillation, 24/40, glass plug
Especially designed receiver to draw samples during distillation or to return the condensed vapor to the flask. Capacity 125ml.
Ace Glass, Inc. Receiver, moisture test, 10mL, 35/20
10mL moisture test receiver with 35/20 spherical joint. Suitable for ASTM D 95 and E 123. Subdivided 0.1mL to 2.0mL, and 0.2mL above 2.0mL.
