Addition Funnels
Ace Glass, Inc. Funnel, addition, 250mL, offset 24/40 bottom joint
Funnel, addition, 250mL, offset 24/40 bottom joint
Ace Glass, Inc. Addition funnel, 19L, #25 Ace-Thred bottom, body only
19L addition/separatory funnel body for use where large volumes are needed. The cylindrical shape necks down to a #25 Ace-Thred.
Chemglass Life Sciences 25mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm PTFE Stpk, 200mm OAH
25mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm PTFE Stopcock, 200mm OAH. Cylindrical style addition funnel similar to CG-1710, but with a PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 10mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm Glass Stpk, 210mm OAH
10mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm Glass Stopcock, 210mm OAH. Cylindrical style addition funnel graduated with a double scale of numbers, one up from the stopcock and one down from the capacity line. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 250mL Addition Funnel, Graduated, 29/26 Joint Size, 2mm PTFE Stpk, 350mm OAH
250mL Addition Funnel, Graduated, 29/26 Joint Size, 2mm PTFE Stopcock, 350mm OAH. Cylindrical style addition funnel similar to CG-1710, but with a PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 150mL Funnel, Cold Addition, 24/40 Top Outer, 24/40 Lower Inner, 370mm OAL, Airfree, Schlenk
150mL Funnel, Cold Addition, 24/40 Top Outer, 24/40 Lower Inner, 370mm OAL, Airfree, Schlenk. Used in the preparation of block copolymers or any chemical synthesis requiring high vacuum techniques. Funnel features a large diameter ring seal between the coolant container & the addition funnel body. The open cup design of the coolant chamber allows for easy addition of coolant, particularly dry ice chunks. Constructed using grease-free 0-4mm Chem-Vac™ Chem-Cap valves on the pressure equalizing arm & lower inner joint. Positioning of the valves permits the funnel contents to be kept under inert conditions prior to use or during loading. A 14/20 outer joint is sealed on the funnel body above the coolant chamber for syringe sampling of the funnel contents. Funnel has a drain tube on the rear of the coolant chamber. Designed & developed by William J. Swatos & Barton J. Schober, Department Of Materials Science & Engineering, Polymer Science Program, Penn State University
Chemglass Life Sciences 250mL Powder Addition Funnel, 29/26 Joint Size, Auger B
250mL Powder Addition Funnel, 29/26 Joint Size, Auger B. Facilitates the delivery of free-flowing, granular solids into reactions. Pressure equalizing arm is equipped with a vented stopper for air-free operations and also permits access into the delivery stem for easy clean-out. One piece, easily removed grooved PTFE auger delivers powders at a uniform rate. The 250 and 500mL capacities have the larger, deep cut auger (Size B) for use with coarse material. Funnel has a lower inner joint and top outer, both being the size listed.
Chemglass Life Sciences 10mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm PTFE Stpk, 255mm OAH
10mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm PTFE Stopcock, 255mm OAH. Cylindrical style addition funnel similar to CG-1710, but with a PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 1000mL Addition Funnel, Graduated, 29/42 Joint Size, 4mm PTFE Metering Stpk, 535mm OAH
1000mL Addition Funnel, Graduated, 29/42 Joint Size, 4mm PTFE Metering Stopcock, 535mm OAH. Cylindrical style addition funnel with a PTFE adjustable bore metering plug. Turning the adjustment knob allows flow rate to be controlled from dropwise to full flow. For replacement stoppers see CG-3000.
Ace Glass, Inc. 1000mL graduated cylindrical addition funnel with a 24/40 standard taper stopper joint.
1000mL graduated cylindrical addition funnel with a 24/40 standard taper stopper joint. Stopcock and Stopper not supplied.
Ace Glass, Inc. 250mL 24/40 addition funnel, PTFE stopcock plug, ungraduated
250mL short stem addition funnel with 24/40 top and bottom joints, and a PTFE stopcock plug. Funnel is not graduated.
Ace Glass, Inc. Funnel, addition, graduated, metering stopcock, 50mL, 14/20
50mL pressure equalizing addition funnel with PTFE metering stopcock. Features include 14/20 standard taper joints, protected drip-tip, equalizing arm, and double scale graduations calibrated from the stopcock.
Chemglass Life Sciences 500mL Addition Funnel, 24/40 Joint Size, 4mm Stpk, 435mm OAH
500mL Addition Funnel, 24/40 Joint Size, 4mm Stopcock, 435mm OAH. Cylindrical shape addition funnel with PTFE stopcocks. For replacement stoppers see CG-3000.
Chemglass Life Sciences 50mL Powder Addition Funnel, 24/40 Joint Size, Auger A
50mL Powder Addition Funnel, 24/40 Joint Size, Auger A. Facilitates the delivery of free-flowing, granular solids into reactions. Pressure equalizing arm is equipped with a vented stopper for air-free operations and also permits access into the delivery stem for easy clean-out. One piece, easily removed grooved PTFE auger delivers powders at a uniform rate. Funnel has a lower inner joint and top outer, both being the size listed.
