Addition Funnels
Chemglass Life Sciences 25mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm PTFE Stpk, 240mm OAH
25mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm PTFE Stpk, 240mm OAH. Cylindrical style addition funnel similar to CG-1716, but with PTFE stopcocks. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 125mL Addition Funnel, Cooling Jacket, 24/40 Joint Size, 2mm Stpk
125mL Addition Funnel, Cooling Jacket, 24/40 Joint Size, 2mm Stopcock. Jacket permits the cooling of the contents of the funnel by means of dry ice. Drain outlet is 8mm O.D. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm.
Ace Glass, Inc. 50mL powder dispensing funnel vertical type
50mL vertical, compact, screw-feed powder dispensing funnel. Features a flexible PTFE screw thread, a #15 Ace-Thred at the top, and a large, 1-1/4 knob. Top side port is 14/20, bottom joint is 24/40. 9-1/2 overall height.
Chemglass Life Sciences 250mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm Glass Stpk, 200mm OAH
250mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm Glass Stopcock, 200mm OAH. Cylindrical style addition funnel graduated with a double scale of numbers, one up from the stopcock and one down from the capacity line. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 100mL Funnel, Addition, 14/20 Joint Size, 2mm Glass Stpk On Side Arm, Airfree, Schlenk
100mL Funnel, Addition, 14/20 Joint Size, 2mm Glass Stpk On Side Arm, Airfree, Schlenk. Lower outlet is a standard taper inner joint and has a CG-961-01 0-4mm Chem-Vac Chem-Cap valve. Top outer joint is the same size as the lower inner joint. Available with a choice of a 2mm high vacuum glass stopcock having a Stainless Steel constant pressure retaining device or a 0-4mm Chem-Cap Airfree inlet valve. This item comes with the stopcock.
Chemglass Life Sciences 125mL Addition Funnel, Graduated, 29/26 Joint Size, 2mm PTFE Metering Stpk, 295mm OAH
125mL Addition Funnel, Graduated, 29/26 Joint Size, 2mm PTFE Metering Stopcock, 295mm OAH. Cylindrical style addition funnel with a PTFE adjustable bore metering plug. Turning the adjustment knob allows flow rate to be controlled from dropwise to full flow. For replacement stoppers see CG-3000.
Chemglass Life Sciences 1000mL Addition Funnel, Graduated, 29/42 Joint Size, 4mm PTFE Stpk, 535mm OAH
1000mL Addition Funnel, Graduated, 29/42 Joint Size, 4mm PTFE Stpk, 535mm OAH. Cylindrical style addition funnel similar to CG-1716, but with PTFE stopcocks. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences Funnel, Solvent Addition, Stem 12mm OD X 100mm Long
Funnel, Solvent Addition, Stem 12mm OD X 100mm Long. Design of funnel permits addition of solvents to flash chromatography columns without disturbing the silica-gel / packing layer. Lower end of the funnel is closed and the stem has a series of small holes through which the solvent drains. Top of the funnel is 75mm (3in) in diameter with the stem size as listed.
Chemglass Life Sciences 150mL Funnel, Cold Addition, 24/40 Top Outer, 14/20 Lower Inner, 340mm OAL, Airfree, Schlenk
150mL Funnel, Cold Addition, 24/40 Top Outer, 14/20 Lower Inner, 340mm OAL, Airfree, Schlenk. Used in the preparation of block copolymers or any chemical synthesis requiring high vacuum techniques. Funnel features a large diameter ring seal between the coolant container & the addition funnel body. The open cup design of the coolant chamber allows for easy addition of coolant, particularly dry ice chunks. Constructed using grease-free 0-4mm Chem-Vac™ Chem-Cap valves on the pressure equalizing arm & lower inner joint. Positioning of the valves permits the funnel contents to be kept under inert conditions prior to use or during loading. A 14/20 outer joint is sealed on the funnel body above the coolant chamber for syringe sampling of the funnel contents. Funnel has a drain tube on the rear of the coolant chamber. Designed & developed by William J. Swatos & Barton J. Schober, Department Of Materials Science & Engineering, Polymer Science Program, Penn State University
Chemglass Life Sciences 60mL Addition Funnel, 14/20 Joint Size, 2mm PTFE Stpk, 220mm OAH
60mL Addition Funnel, 14/20 Joint Size, 2mm PTFE Stopcock, 220mm OAH. Cylindrical style addition funnel with a standard taper top outer joint and lower inner joint, both being the same size. With pressure equalizing arm and PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Ace Glass, Inc. Addition funnel, 19L, #25 Ace-Thred bottom, body only
19L addition/separatory funnel body for use where large volumes are needed. The cylindrical shape necks down to a #25 Ace-Thred.
Chemglass Life Sciences 25mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm PTFE Stpk, 200mm OAH
25mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm PTFE Stopcock, 200mm OAH. Cylindrical style addition funnel similar to CG-1710, but with a PTFE stopcock. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
Chemglass Life Sciences 60mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm PTFE Metering Stpk, 265mm OAH
60mL Addition Funnel, Graduated, 24/40 Joint Size, 2mm PTFE Metering Stopcock, 265mm OAH. Cylindrical style addition funnel with a PTFE adjustable bore metering plug. Turning the adjustment knob allows flow rate to be controlled from dropwise to full flow. For replacement stoppers see CG-3000.
Chemglass Life Sciences 1000mL Addition Funnel, 24/40 Joint Size, 4mm PTFE Stpk, 520mm OAH
1000mL Addition Funnel, 24/40 Joint Size, 4mm PTFE Stopcock, 520mm OAH. Cylindrical style addition funnel with a standard taper top outer joint and lower inner joint, both being the same size. With pressure equalizing arm and PTFE stopcock. For replacement stoppers see CG-3000.
Chemglass Life Sciences 10mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm Glass Stpk, 210mm OAH
10mL Addition Funnel, Graduated, 14/20 Joint Size, 2mm Glass Stopcock, 210mm OAH. Cylindrical style addition funnel graduated with a double scale of numbers, one up from the stopcock and one down from the capacity line. With a standard taper top outer joint and lower inner joint, both being the same size, and pressure equalizing arm. Funnels with 14/20 and 19/22 joints are supplied complete with a stopper. For replacement stoppers see CG-3000.
