HPLC Columns and Cartridges
Waters Corporation XBridge Prep Column, C18 BEH, 10 μm, 19 x 50 mm
The XBridge BEH C18 sorbent is a versatile tool for HPLC method development, functional across a mobile phase pH range of 1 to 12. Its trifunctionally bonded C18 ligand offers a universal column suitable for most HPLC separations.
- Workhorse for HPLC method development, usable over a mobile phase pH range of 1 to 12.
- Universal column for most HPLC separations due to trifunctionally bonded C18 ligand.
- Widest usable pH range.
- Superior low pH stability.
- Ultra-low column bleed.
Waters Corp Waters Preparative Column, XBridge BEH C18, 10 μm, 19 x 150 mm
The XBridge BEH C18 sorbent facilitates HPLC method development, usable across a mobile phase pH range of 1 to 12. Its trifunctionally bonded C18 ligand provides universal HPLC separations with superior low pH stability and ultra-low column bleed. The Optimum Bed Density (OBD) design enables faster, more effective lab-scale separations and direct scale-up from UPLC or HPLC to purification. This column resists mechanical chromatographic bed failure.
- Usable across a mobile phase pH range of 1 to 12.
- Trifunctionally bonded C18 ligand for universal HPLC separations.
- Superior low pH stability and ultra-low column bleed.
- Improved output and recovery.
- Faster, more effective lab-scale separations.
- Direct scale-up from UPLC or HPLC to lab-scale purification.
- Resistant to mechanical chromatographic bed failure.
- Consistent, predictable density profiles and cavity avoidance.
Waters Corp XBridge BEH C18 OBD Prep Column, 130Å, 10 µm, 19 mm X 250 mm, 1/pk
As a workhorse for HPLC method development, XBridge BEH C18 sorbent can be used over an entire range of mobile phase pH (1-12). The trifunctionally bonded C18 ligand provides you with a universal column for most HPLC separations and gives you the widest usable pH range, superior low pH stability, and ultra-low column bleed.
Waters Corp Waters XBridge Preparative Column, BEH C18, 30 x 150 mm, 10 μm
The Waters XBridge Preparative Column is designed for high-performance liquid chromatography. It features BEH C18 chemistry and is an OBD column, providing robust separation capabilities for various applications.
- 30 x 150 mm dimensions
- 10 μm particle size
- BEH C18 chemistry for broad separation
- Requires a 30 x 10 mm prep guard holder
Waters Corp Waters OBD Prep Column, C18, 10 μm, 50 mm × 150 mm
This BEH C18 sorbent column is designed for HPLC method development, compatible with mobile phase pH 1-12. It offers universal applicability for most HPLC separations, featuring superior low pH stability, minimal column bleed, and exceptional mechanical resistance. It enhances productivity in high-resolution, high-speed screening for preparative HPLC.
- Compatible with mobile phase pH 1-12.
- Trifunctionally bonded C18 ligand for universal HPLC separations.
- Superior low pH stability and ultra-low column bleed.
- Exceptional resistance to mechanical bed failure, ensuring consistent performance and extended lifetime.
- Maximizes productivity in preparative HPLC through high-resolution, high-speed screening, and direct scalability.
Waters Corp Waters OBD Prep Column, C18, 130Å, 10 μm, 50 mm × 250 mm
The BEH C18 sorbent is a robust solution for HPLC method development, functional across a mobile phase pH range of 1–12. It features a trifunctionally bonded C18 ligand, making it a versatile column for a wide array of HPLC separations. This design ensures the broadest usable pH range, excellent stability at low pH, and minimal column bleed.
- Chemistry: C18
- Separation mode: Reversed phase
- pH range: 1–12
- Temperature limits: 80°C (low pH) and 60°C (high pH)
- Maximum pressure: 6000 psi (415 bar)
- Endcapped: Yes
- Silanol activity: Low
- Particle shape: Spherical
- Particle size: 10 μm
- Pore size: 130 Å
- Inner diameter: 50 mm
- Length: 250 mm
- Carbon load: 18%
- Techniques: LC/MS, LC
- USP classification: L1
Waters Corp Waters Column, BEH Shield RP18, 1.7 μm, 2.1 x 30 mm
This column offers alternate selectivity, providing superior peak asymmetry, efficiency, and chemical stability across a wide pH range.
- Complements C18 and C8 phases for alternate selectivity.
- Features an embedded carbamate group, enhancing selectivity for phenolic compounds.
- C18 chemistry, reversed phase separation, and hybrid particle substrate.
- Spherical 1.7 μm particles, 2.1 mm inner diameter, 30 mm length.
- 130 Å pore size, 185 surface area, and 17 % carbon load.
- Operates from pH 2 to 11 with maximum pressure of 18000 psi (1240 Bar).
- Compatible with UPLC/UHPLC systems; utilizes BEH particle technology and eCord.
- Delivers excellent peak asymmetry, efficiency, and chemical stability.
Waters Corporation Column, Phenyl, 1.7 μm, 130 Å, 2.1 mm x 30 mm
The ACQUITY BEH Phenyl Column offers complementary selectivity to C18 stationary phases, particularly for polyaromatic compounds. This chemically stable phenyl sorbent provides ultra-low column bleed, long lifetimes, and excellent peak shape, ensuring high reproducibility and minimizing method variation.
- Offers complementary selectivity to C18 stationary phases for polyaromatic compounds.
- Chemically stable phenyl sorbent with ultra-low column bleed and long column lifetimes.
- Ensures batch-to-batch reproducibility.
- Features a wide pH stability range of 1 to 12.
- Manufactured under strict ISO 9001 conditions.
- Each column is individually tested; results available via eCord™ Intelligent Chip.
Waters Corp Waters Prep Column, BEH C18, 5 μm, 50 × 50 mm
This preparative column features robust BEH C18 sorbent for HPLC method development, compatible with a wide mobile phase pH range of 1–12. It offers excellent low pH stability and minimal column bleed for various HPLC separations.
- Chemistry: C18
- Separation mode: Reversed phase
- Particle substrate: Hybrid
- pH range: 1–12
- Temp limits: 80°C (low pH), 60°C (high pH)
- Max pressure: 6000 psi (415 bar)
- Endcapped; Low silanol activity
- Particle: Spherical, 5 μm
- Pore size: 130 Å
- Format: OBD prep column
- Surface area: 185 m²/g
- System: HPLC preparative
- Technique: LC/MS, LC
- USP classification: L1
- Dimensions: 50 mm ID x 50 mm length
- Carbon load: 18%
Waters Corp Waters Prep Column, C8, 5 μm, 130 Å, 50 mm X 50 mm
The XBridge BEH C8 sorbent is less retentive compared to the XBridge BEH C18 sorbent. It is preferred for method development to achieve faster speeds while improving peak shape and chromatographic performance. The trifunctionally bonded sorbent provides the widest usable pH range (1 to 12), superior low pH stability, and ultra-low column bleed.
- C8 chemistry
- Hybrid particle substrate
- pH range of 1 to 12
- Temperature limits of 60°C (low and high pH)
- Maximum pressure of 6000 psi (415 Bar)
- Low silanol activity
- Spherical 5 μm particle size
- 130 Å pore size
- 50 mm inner diameter by 50 mm length
- HPLC preparative system compatible
Waters Corp WATERS CORPORATION XBridge BEH Shield RP18 OBD Prep Column, 130Å, 5 μm, 50 mm × 50 mm
The XBridge BEH Shield RP18 columns are designed to complement XBridge BEH C18 and C8 phases, offering a valuable tool for HPLC method development. These columns feature an embedded carbamate group in the bonded phase ligand, which provides alternate selectivity, particularly for phenolic compounds, when compared to traditional straight-chain alkyl columns.
- Alternate selectivity, especially for phenolic compounds
- Embedded carbamate group in the bonded phase ligand
- Complements C18 and C8 phases
- Embedded polar C18 providing different selectivity with improved peak shape for basic compounds
Waters Corp Waters Prep Column, Phenyl, 5 μm, 50 mm × 50 mm
This preparative column offers complementary selectivity to C18 stationary phases for polyaromatic compounds. It uses a stable Phenyl sorbent for ultra-low column bleed, extended lifetimes, and excellent peak shapes. Constructed with hybrid particle substrate and phenyl-hexyl bonding, it has a spherical particle with low silanol activity. It operates within a pH range of 1 to 12 and handles temperatures up to 80°C (low pH) or 60°C (high pH), with a maximum pressure of 6000 psi (415 Bar). Suitable for HPLC preparative and LC/MS techniques.
- Complementary selectivity to C18 stationary phases, especially for polyaromatic compounds.
- Most chemically stable commercially available Phenyl sorbent on the market.
- Provides ultra-low column bleed.
- Offers long column lifetimes.
- Ensures excellent peak shape.
- Endcapped.
- Low silanol activity.
- Spherical particle shape.
Waters Corporation OBD Prep Column, C18, 130Å, 5 μm, 50 mm X 100 mm
This C18 sorbent supports HPLC method development across a mobile phase pH range of 1 to 12. Its trifunctionally bonded C18 ligand provides a universal column for most HPLC separations, offering a wide usable pH range, superior low pH stability, and ultra-low column bleed.
- Chemistry: C18
- Separation mode: Reversed phase
- Particle substrate: Hybrid
- pH range: 1 to 12
- Temperature limits: 80°C (low pH) to 60°C (high pH)
- Maximum pressure: 6000 psi (415 bar)
- Endcapped: Yes
- Silanol activity: Low
- Particle shape: Spherical
- Particle size: 5 μm
- Pore size: 130 Å
- Surface area: 185
- Technique: LC/MS, LC
- USP classification: L1
- Inner diameter: 50 mm
- Length: 100 mm
- Carbon load: 18%
Waters Corp XBridge BEH Phenyl OBD Prep Column, 130Å, 5 µm, 50 mm X 100 mm, 1/pk
XBridge BEH Phenyl columns provide complementary selectivity to C18 stationary phases, especially for polyaromatic compounds. This most chemically stable commercially available Phenyl sorbent on the market and provides you with ultra-low column bleed, long column lifetimes and excellent peak shape.
Waters Corporation Column, HSS T3, 1.8 μm, 2.1 mm × 30 mm, 100 Å
The ACQUITY UPLC HSS T3 Column features a universal, silica-based bonded phase compatible with 100% aqueous mobile phase, ideal for separating both polar and non-polar compounds. It provides ultra-low MS bleed, is scalable, and transferable to HPLC. The column’s thermally treated High Strength Silica (HSS) particles ensure robustness under high UPLC pressures and enhanced analyte retention.
- Compatible with 100% aqueous mobile phase.
- Increased retention for polar and non-polar analytes.
- Mechanically stable under high UPLC system pressures.
- Maximizes selectivity space for diverse chromatographic interactions.
- Seamless integration with UPLC systems.
- High efficiencies and best-in-class column stability.
- Facilitates high-throughput method development.
- Performance verified with Neutrals and Reversed-Phase QC Reference Materials.
